3M™ Membrane Switch Spacer 7961MP, Clear, 24 in x 36 in, 11.0 mil, 50 sheets per, pack 1 per case

SKU: 7100179432

3M™ Membrane Switch Spacer 7961MP, Clear, 24 in x 36 in, 11.0 mil, 50 sheets per, pack 1 per case

SKU: 7100179432
$19.18 / Sheet
Add $199.00 worth of items to your cart to qualify for free shipping

Minimum Order Quantity: 50 Sheet
QTY:
SHIPPING DIMENSIONS Height: 2.31 Inches Width: 25.81 Inches Length: 37.44 Inches Weight: 37 Lb(s) 9 Oz

Product Benefits

  • 11 mil double-coated spacer is ideal for withstanding repeated stress of switch actuation
  • Layflat 58 lb. polycoated kraft (PCK) liners add dimensional stability for various die-cutting operations
  • 2 mil acrylic adhesive on each side delivers excellent shear strength, resists slippage and edge lifting
  • 7 mil polyester film carrier provides strength and stability
  • Adhesive resists oozing at edges and die-cuts for faster part processing

More Product Details

The High-Shear Advantage – Less Oozing and Tighter Edges
Featuring 3M™ High Performance Acrylic Adhesive 200MP, 3M™ Membrane Switch Spacer 7961MP is ideal for the stresses of switch actuation over long periods. The adhesive on this double-sided spacer is formulated for excellent shear strength – forming a durable bond with plastics and other smooth surfaces with less oozing at the edges. This allows for easier slitting and die-cutting, faster part processing and minimal waste. The adhesive is applied at 2.0 mils to each side of a 7.0 mil polyester film carrier which adds structural strength.

Double 4.2 mil 58 lb. polycoated kraft (PCK) paper lay-flat liners are designed to cover adhesive consistently for full bonding performance after application. Liners resist curling, tunneling and buckling, increase dimensional stability and hold up even under high humidity for efficient storage and processing. Liner design also enables improved rotary die-cutting at high speeds, as well as improved sheet processing.

Recommended Applications

  • Membrane switch spacers
  • Switch mounting
  • Circuit layer assembly
  • Metal dome placement
  • Lead protection
  • Die-cut laminations

Resilient and Ready
3M™ Membrane Switch Spacer 7961MP is constructed with 2.0 mil high performance acrylic adhesive that is coated on each side of a 7.0 mil polyester film carrier. This membrane switch spacer comes double-linered with a 4.2 mil, 58 lb. moisture-resistant, lay-flat, PCK paper. Designed to separate switch circuitry until actuation, Membrane Switch Spacer 7961MP provides excellent temperature resistance (up to 400?F/204?C short-term heat resistance), solvents and UV resistance.

About High Performance Acrylic Adhesive 200MP
3M™ High Performance Acrylic Adhesive 200MP is considered an industry standard for graphic attachment and general industrial joining applications. It features outstanding adhesion to metal, polycarbonate (PC), ABS and polyester (PET), making it popular across many industries. This adhesive provides some initial repositionability for placement accuracy when bonding to plastics. It also performs well after exposure to humidity and hot/cold cycles, providing confidence that the switch will perform through difficult environmental conditions and millions of actuations.

The Right Choice for a Range of Applications
With low cost, long life, outstanding environmental performance and eye-catching graphics, membrane switches are found in more and more applications. They range from farm tractors and medical test systems to microwave ovens and fish finders. Whatever the need, 3M has a membrane switch construction suited for the job.

Bringing Better Ideas to the Surface through Science
The 3M Industrial Adhesives and Tapes Division applies the science of adhesion to deliver innovative solutions that improve the design and manufacturing processes of companies around the world. In the end, 3M IATD technologies help customers like you deliver competitive products to the market faster and more efficiently.
